| Overall Length*Width*Height | 2300x 1220 x 1350（mm） |
| Curb Weight | 386(kg) |
| Wheel Base | 1480（mm） |
| Wheel Base（Front/Rear） | 1008/965（mm） |
| Seat Height | 860（mm） |
| Ground Clearance | 254（mm） |
| Front Tyre / Type | 25x8-12 |
| Rear Tyre / Type | 25x10-12 |
| Turning diameter | 7.6 (m) |
| Fuel Capacity | 25(L) |
| ENGINE Type | Liquid-cooled，SOHC 8v，Single Cylinder |
| Displacement | 577 (cc) |
| Bore × Stroke | 99x75(mm) |
| Maximum Horsepower | 36/7300 （kw/rpm） |
| Maximum Torque | 55/5500 （N.m/rpm） |
| 1. Front and rear double A rocker arm independent suspension. 2. Front and rear airbag shock absorber (high configuration). 3. Electric control conversion two-wheel drive switch, front axle / rear axle differential lock (optional). 4. Front / rear double A-arm independent suspension (stroke 216/221mm) + balance rod independent suspension. 5. Whole vehicle LED lamps and lanterns. 6. Electric power steering (EPS). 7. 7-inch TFT LCD intelligent screen instrument. 8. Variable middle diameter adjustable airbag has ideal stiffness curve, which can effectively improve the off-road and driving comfort of the whole vehicle. 9. Centralized maintenance layout of instrument cover, highlighting the convenience of vehicle inspection and maintenance. 10. 15m cable is enough to get out of danger in any harsh environment, with a traction capacity of 1650 pounds (750KG), so that the whole vehicle can face all kinds of working conditions calmly. | |
