Power

Engine Type

70CC , Single Cylinder, 4-Stroke, Air Cooled

Displacement：71.8 ml

Bore x Stroke: Ф47×41.4mm

Max Power: 3.75/8500±500 kw/r/min

Max Torque: 5.0/5500±500 N.m/r/min

Compression Ratio: 8.8:1

Shift Type: Automatic clutch, One gear

Start Type: Electric Start

Ignition : CDI

Drive Train: #420 Chain, FT: 14T/RR: 39T Sprocket

Performance

Front Fork：Φ27*550mm Telescopic Forks, 80mm Travel

Rear Shock:  12*270mm None-Adjustable Shock, 50mm Travel

Front Wheel :Steel Rim, FT: 1.40 x 10

Rear Wheel: Steel Rim, RR: 1.40 x 10

Front Tires :2.50-10

Rear Tires: 2.50-10

Front Brake: Single Piston Caliper, 190mm Disc

Rear Brake: Single Piston Caliper, 190mm Disc

Details

Frame: Cradle Type Steel Tube Frame

Swing-Arm: 12' Tube Steel Swingarm

Handle Bar: Aluminum #6061

Overall Size: 1540*710*1020mm

Packing Size: 1405x380x675mm

Wheel Base: 1005 mm

Seat Height: 580 mm

Ground Clearance: 170 mm

Fuel Capacity: 3.5L / 0.92 Gal.

N.W: 50.5KG

G.W: 57.5KG
