Power

Engine Type

150cc, Single Cylinder, 4-Stroke, Oil Cooled

Displacement

155.5 ml

Bore x Stroke

Ф60×55mm

Max Power

10.5/9500±500 kw/r/min

Max Torque

11.5/8000±500 N.m/r/min

Compression Ratio

11.5:1

Shift Type

Manual Wet Multi-Plate, N-1-2-3-4, 4-Gears

Start Type

Kick Start

Ignition

Digital CDI

Drive Train

#428 Chain, FT: 14T/RR: 41T Sprocket

Performance

Front Fork

Φ45*Φ48-780mm Inverted Hydraulic Forks, 130mm Travel

Rear Shock

10*410mm None-Adjustable Shock, 80mm Travel

Front Wheel

6063 Aluminum Rim, FT: 1.6 x 19

Rear Wheel

6063 Aluminum Rim, RR: 2.15 x 16

Front Tires

80/100-19

Rear Tires

100/90-16

Front Brake

Dual Piston Caliper, 240mm Disc

Rear Brake

Single Piston Caliper, 240mm Disc

Details

Frame

Perimeter Cradle Type Steel Frame

Swing-Arm

Tube High Strength Steel Swingarm;L=560mm

Handle Bar

Tapered Aluminum #6061

Overall Size

1690x725x1100 mm

Packing Size

1670x415x795mm

Wheel Base

1320 mm

Seat Height

820 mm

Ground Clearance

300 mm

Fuel Capacity

4.5 L / 1.2 Gal.

N.W

75KG

G.W

85KG
