Power

Engine Type

125CC, Single Cylinder, 4-Stroke, Air Cooled

Displacement

123.6 ml

Bore x Stroke

Ф54×54mm

Max Power

6.0/7500±500 kw/r/min

Max Torque

9.5/5500±500 N.m/r/min

Compression Ratio

9.0:1

Shift Type

Manual , N-1-2-3-4, 4-Gears

Start Type

Electric & Kick Start

Ignition

CDI

Drive Train

#420 Chain, FT: 14T/RR: 41T Sprocket

Performance

Front Fork

Φ45*Φ48-650mm Inverted Hydraulic Forks, 120mm Travel

Rear Shock

10*270mm None-Adjustable Shock, 50mm Travel

Front Wheel

Aluminum Rim, FT: 1.60 x 14

Rear Wheel

Aluminum Rim, RR: 1.85 x 12

Front Tires

60/100-14

Rear Tires

80/100-12

Front Brake

Dual Piston Caliper, 220mm Disc

Rear Brake

Single Piston Caliper, 190mm Disc

Details

Frame

Twin Girders Steel Frame

Swing-Arm

Tube High Strength Steel Swingarm

Handle Bar

Aluminum #6061

Overall Size

1520x740x970 mm

Packing Size

1255x335x615mm

Wheel Base

1050 mm

Seat Height

710 mm

Ground Clearance

240 mm

Fuel Capacity

3.5 L / 0.93 Gal.

N.W

62KG

G.W

74KG
